LED Street Lights 528205
Homeland Led Street Lights
a.Structured LED arrays mounted on metal core circuit for optimized light photometric distribution .
b.85×135 precision refractive optical lens designed for various applications
c.Powder coated, minimum 2.0 mil thickness.
d.LED brand :Samgung
e.Driver :Meanwell
f.Dialux simulation service provided.
Description
Application:
City expressway, trunk road, factories, schools, garden, parking lots,pubic parks etc.
Features:
a.Structured LED arrays mounted on metal core circuit for optimized light photo metric distribution.
b.Utilizes high brightness leds , 70 CRI at 4000-4500K and 5650-6300K typical.
c.LM-79 tests and reports are performed in accordance with IESNA standards.
d.System rating is at 50,000 hours.
e.IP65 suitable for wet locations.
f.Temperature Rated at – 40 to 40 C.
g.Contains no lead or mercury.
h.Mounting:
M 1 – wall mount with /- 10 degree of adjustment.
M 2 – lamppost mount /- 10 degree of adjustment.
i.Powder coated, minimum 2.0 mil thickness.
j.Standard colors: Silver .RAL or custom colors available with minimum order quantities and extended lead times.
| Order No. | Angle | CCT | CRI | Luminous Flux | Dimension (mm) | System Power |
| 528205-W10 | 85×135 | 5000K | >=70 | 950 LM | 375*114*112 | 12 W |
| 528205-W15 | 85×135 | 5000K | >=70 | 1125 LM | 375*114*112 | 17W |
| 528205-W20 | 85×135 | 5000K | >=70 | 1500 LM | 375*114*112 | 22W |
| 528205-W25 | 85×135 | 5000K | >=70 | 1875 LM | 375*114*112 | 27W |
| 528205-W30 | 85×135 | 5000K | >=70 | 2250 LM | 375*114*112 | 33W |
