LED Wall Washer Lights 626105
LED Wall Washer Lights
a.Bottom entry bracket optional.
b.Multi-angle and polarized light lens designs not only meet the demands of various lighting design,but also maximizes the utilization of light.
c.Multiple installation design meets different environmental requirements and angle adjustment.
Description
Available with different optics to enhance architectural designs of other specific applications:
Cove Lighting and Wall Grazing,Outdoor architectures outline, amusement park, hotels, malls, square street, bridges and city lighting place. etc.
Features:
a.Input voltage(V):DC24.
b.Control Mode:CC/DMX512.
c.Beam angle:25° 40° 60° 80°30×65° .
d.Working temperature:-35 to 50C.
e.LED lifetime:70,000hours.
f.IP66 suitable for wet location.
| ORDER NO | COLOR | RATED POWER | LUMINOUS FLUX | N.W | G.W | DIMENSION(MM) |
| 626105A | 24 SINGLE/8R8G8B | 27W | 2295/1320LM | 1.4KGS/PCS | 17KGS | 1055*455*205 |
| 626105B | 24 SINGLE/8R8G8B | 51W | 4001/2244LM | 1.4KGS/PCS | 17KGS | 1055*455*205 |
| 626105C | 18 SINGLE/6R6G6B | 20W | 1722/990LM | 1.4KGS/PCS | 17KGS | 1055*455*205 |
| 626105D | 18 SINGLE/6R6G6B | 38W | 3008/1683LM | 1.4KGS/PCS | 17KGS | 1055*455*205 |
| 626105E | 12 SINGLE/4R4G4B | 14W | 1160/660LM | 1.4KGS/PCS | 17KGS | 1055*455*205 |
| 626105F | 12 SINGLE/4R4G4B | 26W | 2005/1122LM | 1.4KGS/PCS | 17KGS | 1055*455*205 |
| 626105G | 9 SINGLE/3R3G3B | 10W | 870/497LM | 0.7KGS/PCS | 8.5KGS | 555*455*205 |
| 626105H | 9 SINGLE/3R3G3B | 20W | 1505/845LM | 0.7KGS/PCS | 8.5KGS | 555*455*205 |
