LED Garden Lights 523208
LED Garden Lights
a.Owned patent,many advanced technologies in this garden light.
b.Fashionable and modern design make the lamp to be the nice sight in the city.
c.Main structure adopts aluminum and PC.
d.Inside reflector design,the light efficiency is much more.
Description
Application:
City expressway, trunk road, factories, schools, garden, parking lots,pubic parks etc.
Features:
a.Color Temperature:6500/4000/3000k.
b.Input Voltage is AC100-277V.
c.Frequency Range:50/60Hz.
d.Power Factor:PF>0.9.
e.Color rendering Index:>70.
f.Installation pipe diameter:Φ60mm.
g.Temperature Rated at -35 to 50C.
h.System rating is at 70,000 hours.
i.IP65.
| ORDER NO. | LED QTY | RATED POWER | LUMINOUS FLUX | N.W | G.W | DIMENSION(MM) |
| 523208A | 48PCS | 58W | 3821/3538/2937LM | 5.30KGS | 7.30KGS | 485*465*575 |
| 523208B | 24PCS | 30W | 1914/1772/1471LM | 5.00KGS | 7.04KGS | 485*465*575 |
| 523208C | 48PCS | 76W | 4662/4289/3517LM | 5.90KGS | 8.50KGS | 485*465*575 |
| 523208D | 24PCS | 60W | 3024/2782/2281LM | 5.30KGS | 7.30KGS | 485*465*575 |
| 523208E | 12PCS | 31W | 1531/1408/1154LM | 5.00KGS | 7.04KGS | 485*465*575 |
| 523208F | 48PCS | 58W | 3944/3652/3031LM | 6.20KGS | 8.85KGS | 570*550*660 |
| 523208G | 24PCS | 30W | 1969/1823/1513LM | 5.90KGS | 8.50KGS | 570*550*660 |
| 523208H | 48PCS | 76W | 4812/4427/3630LM | 6.20KGS | 8.85KGS | 570*550*660 |
| 523208I | 24PCS | 60W | 3111/2862/2346LM | 6.20KGS | 8.85KGS | 570*550*660 |
| 523208J | 12PCS | 31W | 1574/1448/1187LM | 5.90KGS | 8.50KGS | 570*550*660 |
| 523208K | 48PCS | 58W | 4356/3961/3228LM | 5.30KGS | 7.30KGS | 485*465*575 |
| 523208L | 48PCS | 76W | 5314/4888/4008LM | 5.90KGS | 8.50KGS | 485*465*575 |
